V4 Radial Flow Pump

Get a Price/Quote

Product Details:

Warranty Yes
Material MS
Usage Domestic, Commercial, Etc
Power Electric
Pressure High Pressure
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

V4 Radial Flow Pump Price And Quantity

Minimum Order Quantity 10 Unit

V4 Radial Flow Pump Product Specifications

Warranty Yes
Power Electric
Usage Domestic, Commercial, Etc
Pressure High Pressure
Material MS

V4 Radial Flow Pump Trade Information

Payment Terms Cash in Advance (CID)
Supply Ability 100 Unit Per Month
Delivery Time 7 Days
Main Domestic Market All India

Product Description

The V4 Radial Flow Pump is a high pressure electric pump made of MS material that can be used for both domestic and commercial purposes. Its powerful motor generates high pressure that ensures consistent water flow even in multi-story buildings. The pump is equipped with advanced radial flow technology that enhances its performance and durability. With its robust construction, the V4 Radial Flow Pump can withstand harsh weather conditions and regular wear and tear. It comes with a warranty that guarantees its reliability and quality.

Construction Materials of Pump

NAME OF PARTS	V-4 RADIAL FLOW	V-4 MIXED FLOW
Impeller/Diffuser	Noryl	Noryl
Stage Casting	Noryl	Noryl + Stainless Steel
Pump Shell	Stainless Steel	Stainless Steel
Bearing Bush	Leaded Bronze	Leaded Bronze
Pump Shaft	Stainless Steel 410/431 Grade	Stainless Steel 410/431 Grade
Suction Bracket	Cast Iron / Brass	Cast Iron / Brass
Hardware	S.S.304	S.S.304

Construction Materials of Motor

NAME OF PARTS	V - 4 RADIAL FLOW	V - 4 MIXED FLOW
Shaft	S.S. 431 / S.S. 410	S.S. 431 / S.S. 410
Bearing Bush	Leaded Bronze	Leaded Bronze
Thrust Bearing	Stainless Steel & Engineering Plastic	Stainless Steel & Engineering Plastic
Lower & Upper Housing	Cast Iron / Brass	Cast Iron / Brass
Stator Shell	Stainless Steel	Stainless Steel
Hardware	Stainless Steel	S.S.304

Operating Limitations

SPECIFICATIONS	V-4 RADIAL FLOW	V-4 MIXED FLOW
H.P. Range	0.5 H.P. to 5.0 H.P.	1.0 H.P. to 5.0 H.P.
Head Range	20 Meters to 150 Meters	150 Meters to 250 Meters
Discharge At Duty Point	20 LPM to 100 LPM	150 LPM to 220 LPM
Max. Discharge	200 Liters	300 Liters
Max. Head / Stage	5.5 Meters	4.0 Meters
Operating Voltage	160-250 Volt (I Phase) 350-440 Volt (III Phase	160-250 Volt (I Phase) 350-440 Volt (III Phase)
Max. Temp. of Liquid	40deg C	40 deg C
Max. Permissible Amount of Sand In The Water	40 to 50 Grams/Cubic Meter	50 to 90 Grams/Cubic Meter

FAQs of V4 Radial Flow Pump:

Q: What is the maximum pressure generated by the V4 Radial Flow Pump?

A: The V4 Radial Flow Pump generates high pressure that ensures consistent water flow even in multi-story buildings.

Q: What is the material used to manufacture the V4 Radial Flow Pump?

A: The V4 Radial Flow Pump is made of MS material that ensures its robustness and durability.

Q: Is the V4 Radial Flow Pump suitable for domestic use?

A: Yes, the V4 Radial Flow Pump is designed for both domestic and commercial purposes.

Q: Does the V4 Radial Flow Pump come with a warranty?

A: Yes, the V4 Radial Flow Pump comes with a warranty that guarantees its reliability and quality.

Q: Is the V4 Radial Flow Pump resistant to regular wear and tear?

A: Yes, the V4 Radial Flow Pump is made of MS material that can withstand harsh weather conditions and regular wear and tear.

Tell us about your requirement

Price:

Quantity *

Quantity

Select Unit

50
100
200
250
500
1000+

Additional detail

Mobile number

Other Products in 'V4 Submersible Pump Sets' category

V4 Mix Flow Pump Sets Minimum Order Quantity : 1 Usage : Domestic, Commercial, Etc Material : MS Application : Submersible Warranty : Yes Power : Electric Pressure : High Pressure Color : Silver
